The Roland V-02HD Multi-Format Video Mixer is a video production problem-solver that offers a switcher, scaler, expander, along with audio processing and video effects - being the perfect companion at events or productions which often bring serious challenges.
The advanced Roland V-02HD Multi-Format Video Mixer replaces majority standalone units, packing a variety of powerful features into a really compact sized construction, making it aldo really easy to pack in your case. It features a screw tap for standard video mounts and easily attaches onto a tripod to stay out of the way.
Some powerful features that's loaded onto the Roland V-02HD allows you to seamlessly switch between two HDMI sources and it also features the T-bar for really smooth transitions; effects select; a menu button; and a graphics select knob.
Dual camera / single operator productions
The V-02HD takes the HDMI output from two cameras and seamlessly switches to a connected recorder or live streaming encoder. The operator can then switch between cameras using the dedicated controls or even by using their feet, via a connected footswitch that lets them continue operating their camera. Audio from both cameras and external sources can be mixed together within the V-02HD and monitored through dedicated headphone output. Finally, the resulting mix is embedded with the video switch and output over HDMI. The V-02HD transforms a two-camera shoot into a small one-person production studio, for reliable recording or live-streaming even with minimal resources.
Simple, seamless switching
Switching sources in a small presentation can be a pain, whether its signal loss to the main display or the computers inability to handle unexpected input signals. The V-02HD ensures a professional cross-dissolve switchover between computers and screens, maintaining hi-res pixel-accurate display resolution with deep 10-bit 4:4:4 color space. With simple two-button operation, anyone can pull off professional switching of multiple sources, even if using the V-02HD for the first time.
The input/output matchmaker
Having two HDMI-equipped devices doesnt mean theyre compatible, especially when it comes to video signals in a variety of resolutions for example, a tablets output may not display properly on the receiving display. With both input and output scalers, the V-02HD can take SD, HD, and computer resolutions, before resizing them to fit the display and then outputting in a new resolution thats compatible with the receiving device.
To embed or de-embed? Why not both?
The V-02HD not only lets you embed analog audio into an HDMI signal for recording or live streaming but you can also extract the audio from an HDMI signal to send over to a larger dedicated audio mixer. Where many converters only support digital audio, or offer either embedding or de-embedding (and not both), the V-02HD lets you do it all.
Onboard toolkit for fixing your audio
The V-02HD has three-band EQ and dynamics onboard, so you can immediately optimize your audio without having to send to an external mixing desk. A built-in effects library is packed with presets for common production scenarios including interviews, ambient sound recording, and eliminating wind noise when filming outdoors. These tools even work with inline HDMI signals, so you can fix your audio issues without leaving the digital domain.
When you just need one more input
Its frustrating when your switcher needs one more input and youre all out of options. With two extremely low latency inputs, the V-02HD provides that prized additional connection without adding any perceptible delay to your camera inputs. And with high-resolution 10-bit 4:4:4 color space, theres no signal degradation either.
Incorporate time-saving, professional-looking effects in real-time
Although adding effects via your editing package is becoming easier, more complex effects for example, blurring a persons face for privacy purposes require time and extensive knowledge of video-editing software. Or you could just add the effect directly to the cameras output and record the result. The V-02HD has 14 visual effects that can be applied in real-time, with adjustable parameters to fine-tune the results plus an additional 5 composition effects so you can add titles, use a green screen with the Key effect, or create a separate inset window with the PinP capability.
Picture your back-up plan
When an input source fails in a presentation or a new speaker arrives but isnt ready to present, the last thing you want to display is a blank screen; or worse, content that wasnt meant to be shared. You can be ready with a still image loaded into the V-02HD placed in between a switcher that doesnt have still image capability and the output display. Simply switch over to the still image in case of emergency.
Control the scene
The dedicated V-02HD remote control app turns your iPad into a gorgeous touch interface for the V-02HD. You can operate the switching functions of the V-02HD, mix audio with virtual faders, change settings and effect parameters quickly and create up to eight custom scenes for fast set-up changes using preset memories. You can also save and restore V-02HD system settings using the Remote Control Utility.
- Roland V-02HD Multi-Format Video Mixer
- AC Adapter
- Power Cord
- Cord Hook
Video Processing | 4:4:4 (YPbPr), 10-Bit |
Connectors | Input 2 x HDMI Type A Output 1 x HDMI Type A (Program) 1 x HDMI Type A (Preview) |
Broadcast System | NTSC PAL |
Input Formats | Video 1920 x 1080p: 59.94/50 1920 x 1080i: 59.94/50 1280 x 720p: 59.94/50 576p/i: 50 480p/i: 59.94 Computer (60 Hz) 1920 x 1200 (WUXGA) 1600 x 1200 (UXGA) 1400 x 1050 (SXGA+) 1280 x 1024 (SXGA) 1366 x 768 (FWXGA) 1280 x 800 (WXGA) 1024 x 768 (XGA) 800 x 600 (SVGA) 640 x 480 (VGA) 1920 x 1200: 60 (Reduced Blanking) |
Output Formats | Video 1920 x 1080p: 59.94/50 1920 x 1080i: 59.94/50 1280 x 720p: 59.94/50 576p: 50 480p: 59.94 Computer (60 Hz) 1920 x 1200 (WUXGA) 1600 x 1200 (UXGA) 1400 x 1050 (SXGA+) 1280 x 1024 (SXGA) 1366 x 768 (FWXGA) 1280 x 800 (WXGA) 1024 x 768 (XGA) 800 x 600 (SVGA) 1920 x 1200: 60 (Reduced Blanking) |
Audio Processing | Sampling Rate: 24-Bit, 48 kHz |
Audio Formats | Linear PCM, 24-Bit, 48 kHz, 2-ch |
Connectors | Input 2 x HDMI Type A (Shared with Video) 1 x 3.5 mm Stereo Output 1 x HDMI Type A (Program, Shared with Video) 1 x HDMI Type A (Preview, Shared with Video) 1 x 3.5 mm Stereo Mini |
Other Specs | Input Level -10 dBu (+8 dBu Max) Output Level Phones: 92 + 92 mW (32 Ohms) Input Impedance 45 kOhms Output Impedance Phones: 10 Ohms |
Mounting | Tripod: 1/4"-20 Threaded Mounting Hole Desktop: 4 x Rubber Feet |
Interface | USB Memory: USB Type-B (For Backup from PC) CTL/EXP: 1/4" TRS Phone Type |
Power | Supply: AC Adapter Current Draw: 1.1 A Power Consumption: 10 W |
Operating Temperature | 0 to 140°C |
Dimensions | 16 x 10.8 x 5.1 cm |
Weight | 0.6 kg |
