OM SYSTEM OM-5 Mirrorless Camera with 12-45mm f/4 PRO Lens (Black)
OM SYSTEM OM-5 Mirrorless Camera (Black)
- 20.4MP Live MOS Micro Four Thirds Sensor
- TruePic IX Image Processor
- 2.36m-Dot Eye-Level OLED EVF
- 3.0" 1.04m-Dot Vari-Angle Touchscreen
- DCI 4K/24p & UHD 4K/30p Video Recording
- 5-Axis Sensor-Shift Image Stabilization
- 30 fps Shooting, ISO 200-25600
- 121-Point All Cross-Type Phase-Detect AF
- High-Res Shot, Live ND & Composite Modes
- Weather-Sealed Construction
Olympus M.Zuiko Digital ED 12-45mm f/4 PRO Lens
- Micro Four Thirds System
- 24-90mm (35mm Equivalent)
- Aperture Range: f/4 to f/22
- 1 DSA Element, 2 Aspherical Elements
Choose options
OM SYSTEM OM-5 Mirrorless Camera (Black)
- 20.4MP Live MOS Micro Four Thirds Sensor
- TruePic IX Image Processor
- 2.36m-Dot Eye-Level OLED EVF
- 3.0" 1.04m-Dot Vari-Angle Touchscreen
- DCI 4K/24p & UHD 4K/30p Video Recording
- 5-Axis Sensor-Shift Image Stabilization
- 30 fps Shooting, ISO 200-25600
- 121-Point All Cross-Type Phase-Detect AF
- High-Res Shot, Live ND & Composite Modes
- Weather-Sealed Construction
Olympus M.Zuiko Digital ED 12-45mm f/4 PRO Lens
- Micro Four Thirds System
- 24-90mm (35mm Equivalent)
- Aperture Range: f/4 to f/22
- 1 DSA Element, 2 Aspherical Elements
OM SYSTEM OM-5 Mirrorless Camera (Black)
- 20.4MP Live MOS Micro Four Thirds Sensor
- TruePic IX Image Processor
- 2.36m-Dot Eye-Level OLED EVF
- 3.0" 1.04m-Dot Vari-Angle Touchscreen
- DCI 4K/24p & UHD 4K/30p Video Recording
- 5-Axis Sensor-Shift Image Stabilization
- 30 fps Shooting, ISO 200-25600
- 121-Point All Cross-Type Phase-Detect AF
- High-Res Shot, Live ND & Composite Modes
- Weather-Sealed Construction
Olympus M.Zuiko Digital ED 12-45mm f/4 PRO Lens
- Micro Four Thirds System
- 24-90mm (35mm Equivalent)
- Aperture Range: f/4 to f/22
- 1 DSA Element, 2 Aspherical Elements
The OM SYSTEM OM-5 Mirrorless Camera is designed to be suitable for a variety of still and video needs in a compact and durable Micro Four Thirds mirrorless body.
The OM SYSTEM OM-5 Mirrorless Camera features a 20.4MP Live MOS sensor as well as an updated TruePix IX image processor with quick continuous shooting up to 30 fps as well as DCI and UHD video recording.
Offering a sensitivity range of up to ISO 25600, the sophisticated 5-axis sensor-shift image stabilisation system compensates for 6.5 stops of camera shake enabling sharper handheld shooting.
The sensor's design incorporates 121 phase-detection points, all of which are cross-type, along with 121 contrast-detection areas for fast and precise focusing and subject-tracking performance.
The Olympus M.Zuiko Digital ED 12-45mm f/4 PRO Lens is designed to capture really smooth, and high-quality images. The compact design is extremely light in weight and is carefully crafted for Micro Four Thirds camera systems and provides a standard wide-angle to portrait zoom, which is ideal for capturing a variety of photography styles.
The lens construction is machined out of brilliant optics and features a dustproof/splashproof construction, and it packs ultra-fast autofocus so that you never have to miss an important shot when you're on the move or even for capturing really fast-moving subjects. Key features of this elegant compact lens include advanced elements that consist of ZERO coating to reduce aberrations, flares and loss of light at the edges for brightness and clarity across the entire scene - all contribute to sharp edge-to-edge images at any focal length; superb macro capabilities with a max 0.25x magnification and a close focusing distance of 12cm (wide-angle) or 23cm (telemacro). The lens also supports focus stacking for up to 15 photos at different focal positions and compositing them into a single photo. Additionally, Smooth bokeh image quality can also be achieved all thanks to its rounded seven-blade diaphragm.
20.4MP Live MOS Sensor and TruePic IX Image Processor
The OM SYSTEM OM-5 Mirrorless Camera features a 20.4MP Live MOS sensor as well as an updated TruePix IX image processor with quick continuous shooting up to 30 fps as well as DCI and UHD video recording.
Offering a sensitivity range of up to ISO 25600, as well as 4K recording capabilities.
121-Point All Cross-Type Phase-Detection AF
The OM SYSTEM OM-5 Mirrorless Camera features quick and accurate 121 phase- as well as a contrast-detection autofocus points. For tracking moving projects, you will find Group Target 25 when shooting moving subjects like birds and wildlife. The Face and Eye Detection has also been upgraded.
5-Axis Sensor-Shift Image Stabilization
The OM SYSTEM OM-5 Mirrorless Camera features in-body, sensor-shift image stabilization. This assists in minimizing camera shake for shooting video handheld by up to 6.5 stops.
This image stabilisation system provides 5-Assis Sensor-Shift Stabilisation. This compensates for vertical angle rotation, horizontal angle rotation, horizontal shift, vertical shift, and rolling camera shake movement.
DCI and UHD 4K Video Recording and OM-Log400
The OM SYSTEM OM-5 Mirrorless Cameras sensor is capable of recording both DCI (4096 x 2160) and UHD (3840 x 2160) 4K movies. For working in DCI, a true 24p frame rate is used, and UHD 4K is available in frame rates of up to 30p.
You will have a Time-Laps Movie mode in recording up to 4K UHD resolution. For better external audio quality capture, you will find a microphone jack, or you can use the built-in stereo microphone.
Body Design and Connectivity
The OM SYSTEM OM-5 Mirrorless Camera features a high-resolution 2.36m-dot electronic viewfinder for eye-level shooting. On the back of the unit, you will find a 3.0" 1.04m-dot LCD monitor with a vari-angle design enabling you to view the screen from a variety of angles and access the menu options.
In-body battery charging is supported via the micro-USM port and the included BLS-50 battery can provide you with approximately 310 shots per charge.
For fast read and write speeds, the single SD card slot is UHS-II compatible. You will also find a microphone port, a top hot shoe, micro-USB as well as micro-HDMI ports. You will also find a 2.5mm port for optional remotes.
The OM SYSTEM OM-5 Mirrorless Camera offers you a rugged splashproof, dustproof, and freezeproof body construction incorporating sealing throughout the body design. Making it perfect for working in inclement weather conditions.
Built-in Wi-Fi, as well as Bluetooth, enables easy sharing of content to a linked device.
OM SYSTEM OM-5 Mirrorless Camera (Black)
- BLS-50 Lithium-Ion Battery
- F-5AC Adapter
- USB Cable
- Shoulder Strap
Olympus M.Zuiko Digital ED 12-45mm f/4 PRO Lens
- Olympus LC-58F Lens Cap for 14-150mm f/3.5-5.6 II Lens
- Olympus LR-2 Rear Lens Cap
- Olympus LH-61G Lens Hood
- CS-53 Wrapping Cloth
OM SYSTEM OM-5 Mirrorless Camera
Imaging
Lens Mount | Micro Four Thirds |
Sensor Resolution | Actual: 21.8 Megapixel Effective: 20.4 Megapixel |
Sensor Type | 17.4 x 13 mm (Four Thirds) MOS |
Crop Factor | 2x |
Image Stabilization | Sensor-Shift, 5-Axis |
Built-In ND Filter | 4-Stop Electronic ND Filter |
Capture Type | Stills & Video |
Extreme Control
Shutter Type | Electronic Shutter, Mechanical Focal Plane Shutter |
Shutter Speed | Mechanical Shutter 1/8000 to 60 Seconds Electronic Front Curtain Shutter 1/320 to 60 Seconds Electronic Shutter 1/32000 to 60 Seconds |
Bulb/Time Mode | Bulb Mode, Time Mode |
ISO Sensitivity | 200 to 25,600 (Extended: 64 to 25,600) |
Metering Method | Centre-Weighted Average, Multi-Zone, Spot |
Exposure Modes | Aperture Priority, Auto, Manual, Program, Shutter Priority |
Exposure Compensation | -5 to +5 EV (1/3, 1/2, 1 EV Steps) |
Metering Range | -2 to 20 EV |
White Balance | Presets: Auto, Color Temperature, Custom |
Continuous Shooting | Up to 10 fps at 20.4 MP for up to 149 Frames (Raw) / Unlimited Frames (JPEG) Up to 6 fps at 20.4 MP for Unlimited Frames (Raw) / Unlimited Frames (JPEG) Up to 30 fps at 20.4 MP for up to 18 Frames (Raw) / 20 Frames (JPEG) Up to 10 fps at 20.4 MP for up to 138 Frames (Raw) / Unlimited Frames (JPEG) |
Interval Recording | Yes |
Still Image Capture
Image Sizes | 4:3 JPEG / Raw 20.4 MP (5184 x 3888) 4:3 JPEG 20.4 MP (1024 x 768) 4:3 JPEG 50 MP (8160 x 6120) |
Aspect Ratio | 1:1, 3:2, 4:3, 16:9 |
Image File Format | JPEG, Raw |
Bit Depth | 12-Bit |
Video Capture
Internal Recording Modes | H.264/MOV/MPEG-4 AVC DCI 4K (4096 x 2160) at 24.00 fps [237 Mb/s] H.264/MOV/MPEG-4 AVC UHD 4K (3840 x 2160) at 24.00/25/29.97 fps [102 Mb/s] H.264/MOV/MPEG-4 AVC 1920 x 1080 at 24.00/25/29.97 fps [18 to 202 Mb/s] H.264/MOV/MPEG-4 AVC 1280 x 720 at 24.00/25/29.97/50/59.94 fps [102 Mb/s] MOV 1920 x 1080 at 119.88 fps |
Recording Limit | None |
Broadcast Output | NTSC/PAL |
Built-In Microphone Type | Stereo |
Interface
Media/Memory Card Slot | Single Slot: SD/SDHC (UHS-II) |
Video I/O | 1 x Micro-HDMI Output |
Audio I/O | 1 x 3.5 mm TRS Stereo Microphone Input |
Power I/O | 1 x Micro-USB Input/Output |
Other I/O | 1 x 2.5 mm Sub-Mini Control |
Wireless | Wi-Fi (802.11b/g), Bluetooth |
Global Positioning (GPS, GLONASS, etc.) | None |
Monitor
Size | 3" |
Resolution | 1,040,000 Dot |
Display Type | Articulating Touchscreen LCD |
Viewfinder
Type | Built-In Electronic (OLED) |
Resolution | 2,360,000 Dot |
Eye Point | 27 mm |
Coverage | 100% |
Diopter Adjustment | -4 to +2 |
Focus
Focus Type | Auto and Manual Focus |
Focus Mode | Continuous-Servo AF, Manual Focus, Single-Servo AF |
Autofocus Points | Contrast Detection, Phase Detection: 121 (121 Cross-Type) |
Flash
Built-In Flash | No |
Flash Modes | Fill Flash, Manual, Off, Red-Eye Reduction, Second-Curtain Sync, Slow Sync, Slow Sync/Red-Eye Reduction |
Maximum Sync Speed | 1/250 Second |
Flash Compensation | -3 to +3 EV (1/3, 1 EV Steps) |
Dedicated Flash System | TTL |
External Flash Connection | Hot Shoe |
Environmental
Operating Temperature | -10 to 40°C |
Storage Temperature | -20 to 60°C |
Operating Humidity | 30 to 90% |
Storage Humidity | 10 to 90% |
General
Battery Type | 1 x BLS-50 Rechargeable Lithium-Ion (Approx. 310 Shots) |
Tripod Mounting Thread | 1 x 1/4"-20 Female (Bottom) |
Dimensions (W x H x D) | 125.3 x 85.2 x 49.7 mm |
Weight | 366 g (Body Only) 414 g (With Battery) |
Olympus M.Zuiko Digital ED 12-45mm f/4 PRO Lens
Focal Length | 12 to 45mm (35mm Equivalent Focal Length: 24 to 90mm) |
Maximum Aperture | f/4 |
Minimum Aperture | f/22 |
Lens Mount | Micro Four Thirds |
Lens Format Coverage | Micro Four Thirds |
Angle of View | 84° to 27° |
Minimum Focus Distance | 12 cm |
Maximum Magnification | 0.25x |
Optical Design | 12 Elements in 9 Groups |
Diaphragm Blades | 7, Rounded |
Focus Type | Autofocus |
Image Stabilization | No |
Filter Size | 58 mm (Front) |
Dimensions (ø x L) | 63.4 x 70 mm |
Length at Maximum Extension | 89.3 mm |
Weight | 254 g |
