Hollyland Mars M1 5.5" Wireless Transceiver Monitor Kit (Set of 2)
Choose PayGate at checkout for MobiCred Payments.
- Wirelessly Monitor Video from up to 137.2 m
- Transmitter and Receiver Mode Switching
- 5.5" Touchscreen Display
- Transmit/Receive up to 4K30 Video
- SDI Input, HDMI Input and Output
- Presets and USB Type-C 3D LUT Import
- High 1000 cd/m² Brightness
- Low 0.08s Latency, Smart Channel Scan
- DC Power Input & Output
- Built-In L-Series Battery Plate
Orms Bellville
Orms Cape Town
Hollyland Mars M1 5.5" Wireless Transceiver Monitor Kit (Set of 2)
Orms Bellville
Ground Floor, Tygervalley Chambers 2, 27 Willie Van Schoor Avenue
Bellville
Bellville
Western Cape
7530
South Africa
Orms Cape Town
Shop 5, Roeland Square, Roeland Street
Gardens
Cape Town
Western Cape
8001
South Africa
Choose options
Choose PayGate at checkout for MobiCred Payments.
- Wirelessly Monitor Video from up to 137.2 m
- Transmitter and Receiver Mode Switching
- 5.5" Touchscreen Display
- Transmit/Receive up to 4K30 Video
- SDI Input, HDMI Input and Output
- Presets and USB Type-C 3D LUT Import
- High 1000 cd/m² Brightness
- Low 0.08s Latency, Smart Channel Scan
- DC Power Input & Output
- Built-In L-Series Battery Plate
Choose PayGate at checkout for MobiCred Payments.
- Wirelessly Monitor Video from up to 137.2 m
- Transmitter and Receiver Mode Switching
- 5.5" Touchscreen Display
- Transmit/Receive up to 4K30 Video
- SDI Input, HDMI Input and Output
- Presets and USB Type-C 3D LUT Import
- High 1000 cd/m² Brightness
- Low 0.08s Latency, Smart Channel Scan
- DC Power Input & Output
- Built-In L-Series Battery Plate
The Hollyland Mars M1 5.5" Wireless Transceiver Monitor is designed to transmit, receive, and monitor wireless transmissions. It features a 5.5" touchscreen display with a sharp resolution and 1000 cd/m² brightness.
The Hollyland Mars M1 5.5" Wireless Transceiver Monitor allows you to send and receive video between multiple M1 units as well as to or from Mars 400S Pro, Mars 300 Pro, and Mars 4K wireless transmitters/receivers, wireless transmissions are possible at distances of up to 137.2 m. Furthermore, using the Hollyview App, you are able to view video from the M1 on your smartphone as well.
Display
The Hollyland Mars M1 5.5" Wireless Transceiver Monitor features 1920 x 1080 touch LCD screen with 1000 cd/m² brightness. Supporting the Rec. 709 colour gamut for accurate reproduction, 16:9 aspect ratio, and 16.7m colours.
Compatibility
This monitor is an all-in-one transmitter, receiver, and monitor that you can use as either a transmitter or receiver. The Hollyland Mars M1 5.5" Wireless Transceiver Monitor allows you to send and receive video between multiple M1 units as well as to or from Mars 400S Pro, Mars 300 Pro, and Mars 4K wireless transmitters/receivers, wireless transmissions are possible at distances of up to 137.2 m.
Input/Output
The Mars M1 features HDMI input and HDMI loop output, one 3G-SDI input, as well as a 3.5mm headphone output.
Wirelessly Transmit and Receive Video
For expanded connectivity and compatibility the Hollyland Mars M1 5.5" Wireless Transceiver Monitor supports UHD 4K30 HDMI in and output.
3D LUT File Import
Five selectable 3D LUT presets are available to map the colours to the monitor for a consistent, quality effect. Your own custom LUTs can also be uploaded.
Image Functions
The Mars M1 features multiple built-in functions such as:
- 4x zoom
- Focus assist
- Waveform
- Zebra
- Frame markers
- Auxiliary focus
Wireless Range
Wireless transmissions are possible at distances of up to 137.2m.
Recording and Playback
You will also be able to record or playback video of up to three minutes. Recorded video cannot be exported and will be deleted when the device is turned off or a new recording is started.
Power Options
The Hoolyland Mars M1 Monitor offers you three options to power the device. These include 7 to 16 VDC power input, an L-series (NP-F970/750/550) battery (purchased separately), and a D-Tap connector with a separately available power source.
App Monitoring
Transmissions are possible to be monitored on your iOS or Android using the Hollyview App. It allows you to transmit to apps and receivers and receive from transmitters such as the Mars 400S Pro or Mars 4K in the following configurations:
- M1 TX to 2 M1 RX
- M1 to M1 RX + 2 apps
- M1 to 4 apps
- M1 TX to 2 Mars 400S Pro or Mars 4K receivers
- Mars 400S Pro or Mars 4K transmitter to M1 + 2 apps
Fan Mode
The Hollyland Mars M1 5.5" Wireless Transceiver Monitor features a built-in fan that also features an option to Mute or Auto. Mute mode is ideal for video applications with lower fan noise lowering external noiseon your video.
- Hollyland Mars M1 5.5" Wireless Transceiver Monitor Kit (Set of 2)
Panel Type | |
Display Size | |
Aspect Ratio | |
Touchscreen | |
Image Controls |
Antenna I/O | |
Video I/O | |
Embedded Audio | |
Audio I/O | |
Power I/O | |
Other I/O | |
Encryption |
Wireless Range | |
Frequency Range | |
Wi-Fi | |
Bluetooth |
Video Format | |
Timecode Support |
DC Input Power | |
Battery Type |
Mounting |
Environmental Protection | |
Certifications |
Material of Construction | |
Weight |
