Hollyland Mars 400S SDI/HDMI Wireless Video Transmission System
Choose PayGate at checkout for MobiCred Payments.
- Entry-Level 1080p60 Transmitter/Receiver
- 121m Range; L-Series Battery Plates
- SDI/HDMI Input and Output
- Wi-Fi Transmission to 4 Mobile Devices
Orms Bellville
Orms Cape Town
Hollyland Mars 400S SDI/HDMI Wireless Video Transmission System
Orms Bellville
Ground Floor, Tygervalley Chambers 2, 27 Willie Van Schoor Avenue
Bellville
Bellville
Western Cape
7530
South Africa
Orms Cape Town
Shop 5, Roeland Square, Roeland Street
Gardens
Cape Town
Western Cape
8001
South Africa
Choose options
Choose PayGate at checkout for MobiCred Payments.
- Entry-Level 1080p60 Transmitter/Receiver
- 121m Range; L-Series Battery Plates
- SDI/HDMI Input and Output
- Wi-Fi Transmission to 4 Mobile Devices
Choose PayGate at checkout for MobiCred Payments.
- Entry-Level 1080p60 Transmitter/Receiver
- 121m Range; L-Series Battery Plates
- SDI/HDMI Input and Output
- Wi-Fi Transmission to 4 Mobile Devices
The Hollyland Mars 400S SDI/HDMI Wireless Video Transmission System provides a wireless monitoring system with a 121.92m line-of-sight transmission range. The wireless HD video transmission system offers both HDMI and SDI connection options- expanding your capability options and utilises the latest coding/decoding technology and 5G wireless transmission.
The wireless transmission system is ideal for live broadcasting, sports activities, wedding ceremonies, corporate events and many other events, as it allows users have full control and checking the device status; and supports up to 1080p 60Hz image resolutions. Key features includes an ultra-low latency (less than 0.1s) wireless video transmission; and have full control via the iOS/Android app letting you connect up to 4 app connections; Channel scan that allows you to search for available channels, and also to avoid channels with interference; three application screen modes that include image mode, balance mode, and speed mode. Additionally, it features a low-battery warning indicator that warns you 30 minutes before the battery dies.
- Entry-level 1080p60 transmitter/receiver system
- 121m line-of-sight transmission
- SDI and HDMI input
- SDI and HDMI output
- Up to two receivers supported at the same time
- Wi-Fi transmission to up to four mobile devices using iOS/Android HollyView app
- Built-in L-series battery plates
- OLED display
- Low battery warning
- Channel scan function
- Scene mode selection
- Hollyland Mars 400S SDI/HDMI Wireless Video Transmission System
- Transmitter
- Receiver
- 5 x Antenna
- Shoe Mount
- Expansion Bracket
- DC Adapter
- USB Type-C to USB OTG Adapter
- D-Ring Screw
Wireless Range | 121.92 m (Line-of-Sight) |
Channel Bandwidth | 20 MHz |
Frequency Range | 5 GHz |
Latency | < 0.1 sec |
RF Power | ≤ 21 dBm |
RF Sensitivity | -80 dBm |
Wi-Fi | Yes |
Transmitter Antenna Ports | 2 x RP-SMA Male |
Receiver Antenna Ports | 2 x RP-SMA Male |
Transmitter Video Connectors | 1 x BNC (3G-SDI / HD-SDI) Input 1 x HDMI Input |
Receiver Video Connectors | 1 x BNC (3G-SDI) Output 1 x HDMI Output |
Transmitter Other I/O | 1 x USB Type-C |
Receiver Other I/O | 1 x USB Type-C |
Embedded Audio | SDI HDMI |
Video Format | SDI/BNC: 1080p at 23.98, 24, 25, 29.97, 30, 50, 59.94, 60 fps 1080i at 50, 59.94, 60 fps 1080PsF at 23.98, 24, 25 fps 720p at 50, 59.94, 60 fps HDMI: 1080p at 23.98, 24, 25, 29.97, 30, 50, 59.94, 60 fps 1080i at 50, 59.94, 60 fps 720p at 50, 59.94, 60 fps 576p at 50 fps 480p at 60 fps |
Transmitter Panel Type | OLED |
Receiver Panel Type | OLED |
Transmitter Battery Support | 1 x Sony L-Series / NP-F Type |
Receiver Battery Support | 1 x Sony L-Series / NP-F Type |
Transmitter Power Connector | 1 x Barrel (6 to 16 VDC) Input |
Receiver Power Connector | 1 x Barrel (6 to 16 VDC) Input |
Transmitter Power Consumption | Device: (11 W) |
Receiver Power Consumption | Device: (6 W) |
Transmitter Mounting | 1 x 1/4"-20 Female |
Receiver Mounting | 1 x 1/4"-20 Female |
Materials | Metal |
Transmitter Dimensions | 11.2 x 6.5 x 2.4 cm |
Receiver Dimensions | 11.2 x 6.5 x 2.4 cm |
Transmitter Weight | 192 g |
Receiver Weight | 189 g |
