Hollyland Mars 400S PRO SDI/HDMI Wireless Video Transmission System
Choose PayGate at checkout for MobiCred Payments.
- Transmitter and Receiver Set
- Transmit up to 1080p60 Video
- Transmit up to 120m to RX, 90m to App
- SDI and HDMI Inputs and Outputs
- Powered by USB Type-C, DC Power
- OLED Display, Low-Battery Warning
- Extremely Low 0.1s Latency
- Shoe Adapter and 1/4"-20 Mounting Thread
Orms Cape Town
Hollyland Mars 400S PRO SDI/HDMI Wireless Video Transmission System
Orms Cape Town
Shop 5, Roeland Square, Roeland Street
Gardens
Cape Town
Western Cape
8001
South Africa
Choose options
Choose PayGate at checkout for MobiCred Payments.
- Transmitter and Receiver Set
- Transmit up to 1080p60 Video
- Transmit up to 120m to RX, 90m to App
- SDI and HDMI Inputs and Outputs
- Powered by USB Type-C, DC Power
- OLED Display, Low-Battery Warning
- Extremely Low 0.1s Latency
- Shoe Adapter and 1/4"-20 Mounting Thread
Choose PayGate at checkout for MobiCred Payments.
- Transmitter and Receiver Set
- Transmit up to 1080p60 Video
- Transmit up to 120m to RX, 90m to App
- SDI and HDMI Inputs and Outputs
- Powered by USB Type-C, DC Power
- OLED Display, Low-Battery Warning
- Extremely Low 0.1s Latency
- Shoe Adapter and 1/4"-20 Mounting Thread
The Hollyland Mars 400S PRO-SDI/HDMI Wireless Video Transmission System enables you to add up to 1080p60 video transmission to your gimbal, mirrorless, or DSLR camera rig.
The transmitter provides you with DHMI and SDI inputs, and the received offers you SDI and HDMI outputs. Features up to 120m of the line of sight transmission as well as an extremely low 0.1-second latency to the receiver and up to 90 meters to the Hollyview Wi-Fi app.
The Hollyland Mars 400S PRO SDI/HDMI Wireless Video Transmission System allows you to monitor video transmission in real-time via the Wi-Fi connection. You are additionally able to live-stream via a computer, using the USB Type-C adapter. The transmitter can simultaneously transmit to up to one receiver and two apps, or to a total of four apps without the receiver.
This unit is compact in size, as well as features a bright OLED display for configuration. You will find different mounting options with an integrated shoe adapter with a 1/4"-20 mounting thread.
The transmitter as well as received is powered by USB Type-C or the included locking DC power adapter.
- Transmits up to 1080p60 SDI or HDMI video
- Up to 120 Meters of line-of-sight transmission to the receiver, up to 90 meters to App
- Bright OLED display
- Real-time app monitoring and live streaming via the HollyView app
- Simultaneously transmit to one receiver and two apps, or to four apps
- HDMI and SDI inputs on the transmitter and HDMI and SDI outputs on the receiver
- Two antennas on the transmitter and two antennas on the receiver
- Power via L-series battery, DC adapter, or USB Type-C input
- Integrated shoe adapter with 1/4"-20 mounting thread
- Install optional channel scan firmware via the HollyView app to find the strongest signal
Hollyland Mars 400S PRO SDI/HDMI Wireless Video Transmission System
- Hollyland Mars 400S PRO Transmitter
- Hollyland Mars 400S PRO Receiver
- 5 x Antenna
- DC Power Adapter
Wireless
Wireless Range | 121.92 m (Line-of-Sight) 91.4 m (Line-of-Sight) |
Channel Bandwidth | 20 MHz |
Frequency Range | US: 5 GHz |
Latency | 0.1 sec |
RF Power | < 21 dBm |
RF Sensitivity | -80 dBm |
Interfaces
Transmitter Antenna Ports | 2 x RP-SMA Male |
Receiver Antenna Ports | 2 x RP-SMA Male |
Transmitter Video Connectors | 1 x BNC (3G-SDI / HD-SDI) Input 1 x HDMI Input |
Receiver Video Connectors | 1 x BNC (3G-SDI) Output 1 x HDMI Output |
Transmitter Other I/O | 1 x USB Type-C |
Receiver Other I/O | 1 x USB Type-C |
Embedded Audio | HDMI/SDI |
Format Support
Video Format | SDI/BNC: 1080p at 23.98, 24, 25, 29.97, 30, 50, 59.94, 60 fps 1080i at 50, 59.94, 60 fps 1080PsF at 23.98, 24, 25 fps 720p at 50, 59.94, 60 fps HDMI: 1080p at 23.98, 24, 25, 29.97, 30, 50, 59.94, 60 fps 1080i at 50, 59.94, 60 fps 720p at 50, 59.94, 60 fps 576p at 50 fps 480p at 60 fps |
Display
Transmitter Panel Type | OLED |
Receiver Panel Type | OLED |
Power
Transmitter Built-In Battery | None |
Receiver Built-In Battery | None |
Transmitter Battery Support | 1 x Sony L-Series / NP-F Type |
Receiver Battery Support | 1 x Sony L-Series / NP-F Type |
Transmitter Power Connector | 1 x Barrel (6 to 16 VDC up to 2 A) Input 1 x USB Type-C (5 VDC up to 2 A) Input |
Receiver Power Connector | 1 x Barrel (6 to 16 VDC up to 2 A) Input 1 x USB Type-C (5 VDC up to 2 A) Input |
Transmitter Power Consumption | Power Supply: 6 to 16 VDC (11 W) |
Receiver Power Consumption | Power Supply: 6 to 16 VDC (7 W) |
General
Transmitter Mounting | 1 x 1/4"-20 Female 1 x Cold Shoe |
Receiver Mounting | 1 x 1/4"-20 Female 1 x Cold Shoe |
Transmitter Dimensions | 11 x 7.2 x 3.35 cm |
Receiver Dimensions | 11 x 7.2 x 3.35 cm |
Transmitter Weight | 206 g |
Receiver Weight | 206 g |
