DJI Ronin 4D 4-Axis Cinema Camera 8K Combo Kit
Choose PayGate at checkout for MobiCred Payments.
- Zenmuse X9-8K Camera Gimbal Combo
- Z-Axis Camera/3-Axis Gimbal Stabilizing
- ProRes HQ to 8K30 & Raw Video to 8K75
- Right Focus/Control, Left Pan/Tilt Grips
- 5.5" 1000 cd/m² Touchscreen Display
- LiDAR Range Finder/Focus Module
- 1 x ProSSD 1TB Media Card
- TB50 Intelligent Battery, Mount, Charger
- Carbon Fiber, Aluminum Magnesium Alloy
- Cables, Tools & Carrying Case
Orms Bellville
Orms Cape Town
DJI Ronin 4D 4-Axis Cinema Camera 8K Combo Kit
Orms Bellville
Ground Floor, Tygervalley Chambers 2, 27 Willie Van Schoor Avenue
Bellville
Bellville
Western Cape
7530
South Africa
Orms Cape Town
Shop 5, Roeland Square, Roeland Street
Gardens
Cape Town
Western Cape
8001
South Africa
Choose options
Choose PayGate at checkout for MobiCred Payments.
- Zenmuse X9-8K Camera Gimbal Combo
- Z-Axis Camera/3-Axis Gimbal Stabilizing
- ProRes HQ to 8K30 & Raw Video to 8K75
- Right Focus/Control, Left Pan/Tilt Grips
- 5.5" 1000 cd/m² Touchscreen Display
- LiDAR Range Finder/Focus Module
- 1 x ProSSD 1TB Media Card
- TB50 Intelligent Battery, Mount, Charger
- Carbon Fiber, Aluminum Magnesium Alloy
- Cables, Tools & Carrying Case
Choose PayGate at checkout for MobiCred Payments.
- Zenmuse X9-8K Camera Gimbal Combo
- Z-Axis Camera/3-Axis Gimbal Stabilizing
- ProRes HQ to 8K30 & Raw Video to 8K75
- Right Focus/Control, Left Pan/Tilt Grips
- 5.5" 1000 cd/m² Touchscreen Display
- LiDAR Range Finder/Focus Module
- 1 x ProSSD 1TB Media Card
- TB50 Intelligent Battery, Mount, Charger
- Carbon Fiber, Aluminum Magnesium Alloy
- Cables, Tools & Carrying Case
The DJI Ronin 4D 4-Axis Cinema Camera 8K Combo Kit is an all-in-one camera/gimbal solution designed for the solo use creator as well as dynamic pro video productions.
The X9-8K camera features Z-axis stabilisation built into the camera and the three-axis gimbal stabilisation.
The DJI Ronin 4D-8K features lightweight carbon fibre and an aluminium/magnesium alloy. Making the construction ideal for independent content creators, indie filmmakers, and event videographers.
The Zenmuse X9-8K Full-Frame camera captures up to 8K60 in both ProRes HQ, 8K75 in ProRes Raw, and Ronin's Cine Core 3.0. For the DJI Ronin 4D to be used as a second camera on larger cine-style productions, ACES workflow support is also available among many more functions.
DJI DJI Ronin 4D 4-Axis Cinema Camera 8K Combo Kit includes the main Zenmuse X9-8K full-frame video camera and 3-axis gimbal, plus an array of modular monitor, focusing, and control components. Furthermore, this kit includes a DL lens mount, a LiDAR range finder, one ProSSD 1 TB drive, one TB50 battery, a charging hub, and left and right control handgrips.
Note: A Wireless Video Transmitter is not included in this combo kit.
Please note: In the event that a refund is requested on any DJI product for reasons not based on the rules set out in the Consumer Protection Act, and that product has been registered and/or activated, a 20% handling fee will be applicable.
All-in-One Camera Gimbal System
The DJI Ronin 4D-8K camera gimbal combines imaging, stabilisation and focusing in lightweight carbon fibre and an aluminium/magnesium alloy. Making the construction ideal for independent content creators, indie filmmakers, and event videographers.
The combination design reduces setup time as well as the time between setups and locations.
Included Modular Components
- Left and Right Control Handgrips
- ProSSD 1TB Media Drive
- LiDAR Range Finder
- Top Handle
- Baseplate
CineCore 3.0 Imaging Processing System
The Zenmuse X9-8K is DJI's full-frame camera, employing a proprietary chip for advanced processing and high-performance computing.
The DJI Ronin 4D-8K kit features the CineCore 3.0 supporting internal recording of Apple ProRes Raw, ProRes 422 HQ, and H.264 Video.
Advanced 4-Axis Stabilization
The DJI Ronin 4D 4-Axis Cinema Camera 8K Combo Kit features Z-Axis stabilisation built into the Zenmuse X9-8K and 3-axis stabilisation in the gimbal. Tilt stabilisation uses dual, symmetrical motors and Pan and X axed with additional stiffness buffering.
- Downward ToF (time of flight) sensor
- Forward and downward-facing dual-vision sensors
- Built-in IMU (inertial measurement unit) and barometer
- New and improved stabilization algorithm
Zenmuse X9-8K Camera with DL Lens Mount
The Zenmuse X9-8K camera is compatible with a wide variety of lens mounts, Sony E-Mount or Leica M-Mounts. The DJI Ronin 4D 4-Axis Cinema Camera 8K Combo Kit's DL lens mount supports DJI's current selection of lightweight, carbon fibre 16, 24, 35, and 50mm lenses. With full-frame capture in all lenses named, except for the 16mm DL-Mount lens.
Captures Raw, 4:22 HQ, and H.264
- Captures 8K full-frame raw at rates up to 75 fps in full-frame 2.39:1
- Captures up to 5.5K raw at rates up to 60 fps in Super 35 17:9
- Capture up to 8K30 ProRes 422 HQ video in 17:9 full-frame
- Capture up to DCI 4K60 ProRes 422 HQ or H.264 in 17:9 full-frame or Super35
Dual Native ISO
- 800/5000 dual native ISO
- EI 200 to 12800
- 14+ stops of dynamic range produce nuanced imaging under a range of lighting conditions
In-Camera ND Filters
The DJI Ronin 4D8K features built-in ND.03 to 2.7 filters that enable you to quickly change to different lighting conditions, especially for outdoor shoots with changing cloud cover. Changing between filters make us of a motorised system.
LiDAR Focus Control
Within a 3.3' range the LiDAR system uses up to 43,200 ranging points. The LiDAR system provides you with excellent focusing performance, even in low-light environments, focus pulling can be viewed graphically.
The Modular LiDAR focusing module attaches to the front of the rig.
Autofocus Features
This system even maintains focus, even when motion blur is produced by fast-moving subjects.
As a bonus for solo operators, the DJI Ronin 4D 8K additionally features continued autofocus with ActiveTrack Pro.
Automated Manual Focus
The accuracy of manual focus and ease of autofocus is possible with the AMF function. This is as easy as grabbing the focus wheel on the right handgrip to manually focus.
Dual Focus, Iris, and Control Grips
Right-Hand Grip
The right-hand grip has the focus wheel that additionally doubles as a control for the main camera adjustments like, menus, exposure, and many more functions.
Left-Hand Grip
The left handgrip features a full-range joystick to control pan/tilt, and many more options.
Media Storage Options
In order to capture raw footage, the DJI Ronin 4D 4-Axis Cinema Camera 8K Combo Kit requires a ProSSD 1TB (Included). The USB Type-C port can be used for external recording, no reader is needed to offload footage.
Integrated CFexpress Type-B card slot.
Built-In 5.5" Touchscreen Monitor
- 5.5" 1920 x 1080 monitor
- 1000 cd/m² display
- Touchscreen control
- Rotates for optimal viewing
Audio Recording
For audio recording, the DJI Ronin 4D 4-Axis Cinema Camera 8K Combo Kit feature integrated microphones enabling you to capture dual-channel 24-bit audio. Furthermore a built-in 3.5mm audio input port and XLR port via expanded plate.
Power Options
- Uses the same TB50 intelligent batteries as the DJI Ronin 2 and DJI Inspire 2
- Each battery provides up to 2.5 hours of capture time
- Batteries charge fully in approximately 1.5 hours
- Support auto-heating for cold weather use
- AC adapter for uninterrupted shooting
DJI Ronin 4D 4-Axis Cinema Camera 8K Combo Kit
- Zenmuse X9-8K
- Main Body
- LiDAR Range Finder
- DL Mount
- Left Hand Grip
- Right Hand Grip
- Top Handle
- High-Bright Main Monitor
- ProSSD 1TB
- ProSSD Mount
- TB50 Battery Mount
- Power Adapter
- TB50 Charging Adapter
- 8 x AC Power Cable
- USB-A to USB-C Cable
- USB-C to USB-C Cable
- Base Plate
- Hand Grip Extended Control Sticks
- 3mm Ball-End Hex Key
- 3 x 10mm 1/4"-20 Screw
- Flat He
Imaging
Lens Mount | DL |
Interchangeable Lens Mount | Yes |
Sensor Resolution | Effective: 35.4 Megapixel |
Sensor Type | Full-Frame CMOS |
Image Stabilization | Digital, 4-Axis |
Built-In ND Filter | Mechanical Filter Wheel with Clear, 1 Stop (1/2), 2 Stop (1/4), 3 Stop (1/8), 4 Stop (1/16), 5 Stop (1/32), 6 Stop (1/64), 7 Stop (1/128), 8 Stop (1/256), 9 Stop (1/512) ND Filters |
Internal Filter Holder | Yes |
ISO Sensitivity | 800 to 5000 (Native) 200 to 12,800 |
Shutter Type | Rolling Shutter |
Shutter Speed | 1/24 to 1/8000 sec |
Advertised Dynamic Range | 14 Stops |
White Balance | 2000 to 11,000K |
Gimbal
Rotation Range | Yaw (Pan): 285° Pitch (Tilt): 210° (-55 to 155°) Roll: 70° (-35 to 35°) |
Z-Axis Adjustment Range | 130 mm |
Follow Speed | Pan/Tilt/Roll: 360°/s using DJI Master Wheels or Pro-Force Pan/Tilt/Roll: 120°/s using Ronin 4D Handgrip |
Load Capacity | 960 g |
Internal Recording
Raw Recording | Raw: 8192 x 4320 |
Recording Modes | ProRes 422HQ: 8192 x 4320p at 23.98/24/25/29.97/30 fps 4096 x 2160p at 23.98/24/25/29.97/30/48/50/59.94/60/120 fps H.264 4:2:0 10-Bit: 4096 x 2160p at 23.98/24/25/29.97/30/48/50/59.94/60 fps |
Gamma Curve | HDR-HLG, Rec709 |
Audio Recording | 2-Channel 48 kHz LPCM Audio |
Still Image Support | None |
External Recording
Video Output | USB: 8192 x 4320p at 23.98/24/25/29.97/30 fps 4096 x 2160p at 23.98/24/25/29.97/30/50/59.94/60 fps SDI/BNC: 8192 x 4320p at 23.98/24/25/29.97/30 fps 4096 x 2160p at 23.98/24/25/29.97/59.94/60 fps |
Raw Output | USB In Raw, Full Frame Mode: 8192 x 4320 at 23.98/24/25/29.97/30/50/59.94/60/72/75 fps |
IP Streaming | None |
Interface
Media/Memory Card Slot | Single Slot: DJI ProSSD Single Slot: CFexpress Type B |
Video Connectors | 1 x BNC (3G-SDI) Output 1 x HDMI Output |
Audio Connectors | 1 x 1/8" / 3.5 mm Stereo Mic/Line Level Input 1 x 1/8" / 3.5 mm Stereo Headphone Output |
Built-In Microphone Type | Stereo |
Other I/O | 1 x USB Type-C USB 3.1 Gen 1 Data, Video Input/Output 1 x Proprietary Monitor Output 1 x BNC Timecode |
Monitor
Size | 5.5" |
Resolution | 1920 x 1080 |
Display Type | Tilting Touchscreen LCD |
EVF
EVF | Optional, Not Included |
Power
Battery Type | DJI TB50 |
Power Connectors | 1 x Barrel (12 to 30 VDC) Input |
Environment
Operating Temperature | -10 to 40°C |
Storage Temperature | -20 to 60°C |
Physical
Material of Construction | Carbon Fiber, Aluminum, Magnesium Alloy |
Accessory Mount | 2 x 1/4"-20 Female 1 x 3/8"-16 Female 2 x Cold Shoe Mount |
Dimensions | 309 x 290 x 277 mm (With Protrusions) 235 x 160 x 115 mm (Without Protrusions) |
Weight | 4.67 kg 1.45 kg 1.04 kg |
