Blackmagic Design Ultimatte 12 8K Keyer / Advanced Compositing Processor
Choose PayGate at checkout for MobiCred Payments.
- Up to UHD 8K60 via 12G-SDI BNC
- 1-Touch Keying, Advanced Compositing
- SD/HD/3G/6G/12G-SDI Support
- 32 x SDI Inputs, 20 x Loop Outputs
- Dedicated Compositing Inputs
- Realistic Augmented Reality with Tinting
- Advanced Algorithms and Color Science
- Better Color Fidelity/Edges/Transitions
- Compatible with Ultimatte Smart Remote 4
- 2 RU Rack Size, Redundant Power
Orms Bellville
Orms Cape Town
Blackmagic Design Ultimatte 12 8K Keyer / Advanced Compositing Processor
Orms Bellville
Ground Floor, Tygervalley Chambers 2, 27 Willie Van Schoor Avenue
Bellville
Bellville
Western Cape
7530
South Africa
Orms Cape Town
Shop 5, Roeland Square, Roeland Street
Gardens
Cape Town
Western Cape
8001
South Africa
Choose options
Choose PayGate at checkout for MobiCred Payments.
- Up to UHD 8K60 via 12G-SDI BNC
- 1-Touch Keying, Advanced Compositing
- SD/HD/3G/6G/12G-SDI Support
- 32 x SDI Inputs, 20 x Loop Outputs
- Dedicated Compositing Inputs
- Realistic Augmented Reality with Tinting
- Advanced Algorithms and Color Science
- Better Color Fidelity/Edges/Transitions
- Compatible with Ultimatte Smart Remote 4
- 2 RU Rack Size, Redundant Power
Choose PayGate at checkout for MobiCred Payments.
- Up to UHD 8K60 via 12G-SDI BNC
- 1-Touch Keying, Advanced Compositing
- SD/HD/3G/6G/12G-SDI Support
- 32 x SDI Inputs, 20 x Loop Outputs
- Dedicated Compositing Inputs
- Realistic Augmented Reality with Tinting
- Advanced Algorithms and Color Science
- Better Color Fidelity/Edges/Transitions
- Compatible with Ultimatte Smart Remote 4
- 2 RU Rack Size, Redundant Power
The Blackmagic Design Ultimatte 12 8K Keyer / Advanced Compositing Processor upgrades your real-time compositing for keying live-action video. Adding 12G-SDI connectivity to advanced algorithms, improved still suppression, colour scene and separation while providing excellent colour fidelity to help create photorealistic composites.
The Blackmagic Design Ultimatte 12 8K Keyer / Advanced Compositing Processor works in 8K, UHD, and HD with sub-pixel producing improved images. Offering realistic augmented reality layers and one-touch auto-keying. Additionally, the Blackmagic Design Ultimatte 12 8K Keyer / Advanced Compositing Processor (2 RU) features dual redundant power as well as featuring a 10G Ethernet Port.
Advanced Real-Time Compositing
The Blackmagic Design Ultimatte 12 8K Keyer/Advanced Compositing Processor employs new algorithms and colour science, improved edge handling, colour separation, fidelity and spill suppression to create photorealistic composites in 8K, UHD-4K HD, as well as HD, all in real-time.
Multi-Camera Use
The Blackmagic Design Ultimatte 12 8K Keyer/Advanced Compositing Processor features new technology that enables you to add accurate keying parameters to multiple cameras, this accounts for slight variations between the camera positions.
Realistic Augmented Reality Layer
A new "realistic" layer compositing mode enables you to add translucent or tinted objects on top of the foreground.
One-Touch Keying
The Blackmagic Design Ultimatte 12 8K Keyer/Advanced Compositing Processor offers a one-touch keyer that dramatically reduces editing time, with the auto key you can set over 100 parameters while the set is well-lit and white balanced.
Advanced Image Processing
Advanced image processing algorithms and immense colour space are used to generate internal mattes, so different parts of the image can be processed separately based on the colours in each area. This processing produces fine detail on hair and smooths colour and object transitions 8K, UHD 4K. as well as HD video.
Highest Colour Fidelity
Refined flare, edge, and transition processing make it possible to delete backgrounds without affecting the colours you are retaining.
Shadows and Transparencies
With the improved flare algorithms, one can remove green tinting and spill from almost anything by creating true realistic-looking virtual environments. This is even possible when using shadows or transparent objects with reflections.
High-Quality Interfaces
The Blackmagic Design Ultimatte 12 8K Keyer/Advanced Compositing Processor features high-quality connections that include an Ethernet port, a GPI tally trigger, as well as supporting up to 8K video, and Program video outputs with 12G-SDI BNC ports.
Dedicated Compositing Inputs
Dedicated connectors with loop outputs that are used for compositing include:
Inputs:
- Background
- Background Matte
- Garbage Matte
- Foreground
- Holdout Matte
- Layer
- Layer Matte
Output:
- Program Out
Blackmagic Design Ultimatte 12 8K Keyer/Advanced Compositing Processor
General
Compatibility | Blackmagic Design Ultimatte Smart Remote 4 |
Inputs / Outputs
USB I/O | 1 x USB-C Female Input |
Video I/O | 32 x BNCÂ (12G-SDI) Input 20 x BNCÂ (12G-SDI) Loop Output |
Video Format | 4320p: 60/59.94/50/30/29.97/25/24/23.98 UHD 4K: 60/59.94/50/30/29.97/25/24/23.98 1080p: 60/59.94/50/30/29.97/25/24/23.98 1080psf: 30/29.97/25/24/23.98 1080i: 60/59.94/50 720p: 60/59.94/50 NTSC: 525i 59.94 PAL: 625i 50 |
Video Sampling | 4:2:2 |
Colour Precision | 10-Bit |
Colour Space | Rec. 601, 709, 2020 |
SDI Rate | Multi-Rate Support: 270 Mb, 1.5, 3, 6, 12 Gb/s |
Ethernet | 1 x RJ45 10 Gb/s Ethernet |
Reference Input | 1 x BNC |
Reference Output | 1 x BNC |
GPIO | 1 x 15-Pin GPIO/Tally |
Power
Power Source | AC Input |
AC Input Power | 100 to 240 VAC, 50 / 60 Hz |
Power Consumption | 218 W |
Operating Temperature | 0 to 40°C |
Operating Humidity | 0 to 90% (Non-Condensing) |
Storage Temperature | -20 to 60°C |
Storage Humidity | 0 to 90% (Non-Condensing) |
Physical
Mounting | 1 x 2 RU Rack Unit |
Colour | Black |
Material of Construction | Metal |
Dimensions | 48.3 x 33.8 x 8.84Â cm |
Weight | 8.68 kg |
