Blackmagic Design Micro Converter SDI to HDMI 3G (with Power Supply)
Choose PayGate at checkout for MobiCred Payments.
- 1x SD/HD/3G-SDI Input & 1 x Loop Output
- 1 x HDMI Type A Output
- DCI 2K SDI In/Out | 1080p60 HDMI Out
- AC Power Supply & Socket Adapters
Orms Bellville
Orms Cape Town
Blackmagic Design Micro Converter SDI to HDMI 3G (with Power Supply)
Orms Bellville
Ground Floor, Tygervalley Chambers 2, 27 Willie Van Schoor Avenue
Bellville
Bellville
Western Cape
7530
South Africa
Orms Cape Town
Shop 5, Roeland Square, Roeland Street
Gardens
Cape Town
Western Cape
8001
South Africa
Choose options
Choose PayGate at checkout for MobiCred Payments.
- 1x SD/HD/3G-SDI Input & 1 x Loop Output
- 1 x HDMI Type A Output
- DCI 2K SDI In/Out | 1080p60 HDMI Out
- AC Power Supply & Socket Adapters
Choose PayGate at checkout for MobiCred Payments.
- 1x SD/HD/3G-SDI Input & 1 x Loop Output
- 1 x HDMI Type A Output
- DCI 2K SDI In/Out | 1080p60 HDMI Out
- AC Power Supply & Socket Adapters
The BlackMagic Design Micro Converter SDI to HDMI 3G (with Power Supply) makes it possible to use HDMI-input monitors and televisions for production monitoring. This compact converter has one SD/HD/3G-SDI input, one HDMI output, and one SD/HD/3G-SDI loop output. Included is a 17-point 3D LUT, this can be used for calibration of HDMI- or SDI-input monitors.
The BlackMagic Design Micro Converter SDI to HDMI 3G also can output a LUT for viewing via the SDI loop output. Also featuring automatic SD, HD, and Level A and B SDI detection, also supporting a wide range of pro broadcast resolutions including cine-style 48 fps.
HDMI & SDI Outputs
- One SD/HD/3G-SDI input
- One HDMI output and one SD/HD/3G-SDI loop output
Rugged, Compact Design
The BlackMagic Design Micro Converter SDI to HDMI 3G features a robust metal housing as well as connectors.
Updatable via the USB Type-C port and your Mac or PC.
3D LUT Support
The BlackMagic Design Micro Converter SDI to HDMI 3G supports a 7-point 3D LUT for colour calibrating monitors, TV's, or projectors.
Also featuring LUT outputs for monitoring via SDI loop output.
Wider Resolution Support
- SDI support up to DCI 2Kp60
- HDMI support up to 1080p60
Embedded Audio
Supports embedded HDMI input and embedded SDI output.
Versatile Power Options
The BlackMagic Design Micro Converter SDI to HDMI 3G can be powered using the included 100-240 AC power supply, or the USB-C port ban be used to power the unit from a monitor, laptop or any other compatible component.
- Blackmagic Design Micro Converter SDI to HDMI 3G
- 100-240 VAC Power Supply
- 4 x Socket Adapter
Input
Video Input Connectors | 1 x BNC (3G-SDI / HD-SDI / SD-SDI) |
Input Video Format | SDI (8/10-Bit 4:2:2 RGB, YUV) DCI 2K: 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps DCI 2KPsF: 25/29.97/30 fps 1080p: 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps 1080PsF: 25/29.97/30 fps 1080i: 50/59.94/60 fps 720p: 50/59.94/60 fps NTSC: 59.94 fps PAL: 50 fps |
Audio Input Connectors | None |
Embedded Audio Input | SDI |
Output
Video Output Connectors | 1 x BNC (3G-SDI / HD-SDI / SD-SDI) (Loop Output) 1 x HDMI |
Output Video Format | SDI (8/10-Bit 4:2:2 RGB, YUV) DCI 2K: 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps DCI 2KPsF: 25/29.97/30 fps 1080p: 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps 1080PsF: 25/29.97/30 fps 1080i: 50/59.94/60 fps 720p: 50/59.94/60 fps NTSC: 29.97 fps PAL (768 x 576): 25 fps HDMI (8/10-Bit 4:2:2 RGB, YUV) 1080p: 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps 1080i: 50/59.94/60 fps 720p: 50/59.94/60 fps NTSC: 29.97 fps PAL (768 x 576): 25 fps |
Audio Output Connectors | None |
Embedded Audio Output |
HDMI SDI |
Standards
Video Standard Compliance | SMPTE 259M/292M/296M/424M/425M-A/425M-B |
HDCP Support | Version 2.2 |
Connectivity
Other I/O | 1 x USB Type-C Input |
Expansion Slots | None |
Hardware
Tally Light | Yes |
OS Compatibility | macOS 10.14.15 or Later Windows 10 |
Power
Power Connector | 1 x USB Type-C (4.4 to 5.2 VDC) Input |
Power Consumption | 2.5 W |
Environmental
Operating Temperature | 0 to 40°C |
Storage Temperature | -20 to 60°C |
Operating Humidity | 0 to 90% |
General
Dimensions | 76.45 x 45.7 x 24.89 mm |
Weight | 150 g |
